Baja Designs Dual Sport Kit - EZ Mount - White - 12-1300-WT

12-1300-WT

Description

All Kits Include:
DOT Halogen Hi/Low Glass Lens Headlight
LED Taillight
DOT Turn Signals (flush mount available)
Horn
Ni-Cad Battery (9 ozs)keeps the lights working when the bike is off
Rectifier/Regulator (keeps the battery charged)
Wiring Harness
Switch Panel High Beam Indicator light, turn signal switch, horn, headlight and kill switch
Parts bag contains all necessary nuts, bolts, zip-ties, etc.
Available in all OEM colors including white and black
Detailed installation instructions
Some bikes do not require every component listed above
All states require DOT tires, some states have additional requirements such as Speedo/Odo, mirrors, etc. Please check state requirements.
All-new 2005 switch assembly features a modern style pusho-to-cancel turn signal button and an integrated LED high beam indicator. It now unplugs from the front wiring harness with a quick release connector eliminating the need to unplug any individual components to remove the switch.
EZ Mount Kit:
As many parts pre-mounted as possible. Similar to Quick Release Kit except no rear fender.

Product Series

Application List

YearsMakeModelApplicationNotes
2002 - 2013HondaCRF450RRequires Stator rewind
1979 - 2007HondaCR125RRequires aftermarket stator assembly O.E.M. Color
2003 - 2013HondaCRF150FRequires Stator rewind
1984 - 2001HondaCR500RRequires aftermarket stator assembly O.E.M. Color
1978 - 2007HondaCR250RRequires aftermarket stator assembly O.E.M. Color
1974 - 2007KawasakiKX250Requires aftermarket stator assembly.
2001 - 2003HondaXR80R
2004 - 2011HondaCRF100F
2004 - 2013HondaCRF80F
2007 - 2013HondaCRF150R ExpertRequires Stator rewind
2006 - 2010KTM200 XC-WMust have K2 or K3 ignition installed.
2007 - 2014HondaCRF150RRequires Stator rewind
2004 - 2013HondaCRF250RRequires Stator rewind
2004 - 2013KawasakiKX250FRequires aftermarket stator assembly.
1997 - 1999KTM250 EGSMust have K2 or K3 ignition installed.
2003 - 2006KawasakiKLX125LRequires Stator rewind
1974 - 2005KawasakiKX125Requires aftermarket stator assembly.
2000 - 2001KTM125 EXEMust have K2 or K3 ignition installed.
2006 - 2008KTM250 SXS-FMust have K2 or K3 ignition installed.
2007 - 2008KTM144 SXMust have K2 or K3 ignition installed.
2001 - 2003HondaXR100R
2000 - 2008KTM125 SXSMust have K2 or K3 ignition installed.
1997 - 2005KTM250 EXCMust have K2 or K3 ignition installed.
1997 - 2017KTM125 SXMust have K2 or K3 ignition installed.
2006 - 2013KawasakiKX450FRequires aftermarket stator assembly.
1998 - 2005KTM200 EXCMust have K2 or K3 ignition installed.
2006 - 2010KTM300 XCMust have K2 or K3 ignition installed.
2009 - 2017KTM150 SXMust have K2 or K3 ignition installed.
2000 - 2007HondaXR650R
2005 - 2010KTM250 SX-FMust have K2 or K3 ignition installed.
2006 - 2010KTM250 XCF-WMust have K2 or K3 ignition installed.
1998 - 2004KTM200 SXMust have K2 or K3 ignition installed.
1983 - 2004KawasakiKX500Requires aftermarket stator assembly.
1998 - 2003KTM200 MXCMust have K2 or K3 ignition installed.
1998 - 1999KTM380 EGSMust have K2 or K3 ignition installed.
1996 - 2017KTM250 SXMust have K2 or K3 ignition installed.
2003 - 2006KawasakiKLX125Requires Stator rewind
1997 - 1999KTM300 EGSMust have K2 or K3 ignition installed.
2012 - 2013SuzukiRM-Z450Requires aftermarket stator assembly O.E.M. Color
2006 - 2009KTM200 XCMust have K2 or K3 ignition installed.
1997 - 1999KTM125 EGSMust have K2 or K3 ignition installed.
1997 - 2003KTM250 MXCMust have K2 or K3 ignition installed.
2003 - 2005SuzukiDR-Z110Requires aftermarket stator assembly O.E.M. Color
2006 - 2010KTM300 XC-WMust have K2 or K3 ignition installed.
1997 - 1998KTM125 StingMust have K2 or K3 ignition installed.
1997 - 2005KTM300 MXCMust have K2 or K3 ignition installed.
2000 - 2004YamahaTTR125Requires Stator rewind
2006 - 2010KTM250 XC-WMust have K2 or K3 ignition installed.
1997 - 2007KTM125 EXCMust have K2 or K3 ignition installed.
1997 - 1997KTM360 MXCMust have K2 or K3 ignition installed.
2012 - 2018YamahaYZ125Requires aftermarket stator assembly O.E.M. Color
2003 - 2006KTM525 SXMust have K2 or K3 ignition installed.
2006 - 2009KTM250 XCMust have K2 or K3 ignition installed.
1997 - 1997KTM360 EGSMust have K2 or K3 ignition installed.
2003 - 2005YamahaYZ450FRequires aftermarket stator assembly.
1997 - 1997KTM360 SXMust have K2 or K3 ignition installed.
1998 - 1999KTM200 EGSMust have K2 or K3 ignition installed.
1998 - 2002KTM380 EXCMust have K2 or K3 ignition installed.
1997 - 1997KTM360 EXCMust have K2 or K3 ignition installed.
2003 - 2014SuzukiDR-Z125Requires stator rewind/Requires stator modification.
2000 - 2007KTM250 SXSMust have K2 or K3 ignition installed.
2004 - 2009SuzukiRM-Z250Requires aftermarket stator assembly O.E.M. Color
2000 - 2002KTM520 SXMust have K2 or K3 ignition installed.
1998 - 2002KTM380 SXMust have K2 or K3 ignition installed.
1997 - 2005KTM300 EXCMust have K2 or K3 ignition installed.
2011 - 2011YamahaTTR125L
1976 - 2008SuzukiRM250Requires aftermarket stator assembly O.E.M. Color
2012 - 2018YamahaYZ250Requires aftermarket stator assembly O.E.M. Color
1998 - 2002KTM380 MXCMust have K2 or K3 ignition installed.
2010 - 2013SuzukiRM-Z250Requires aftermarket stator assembly O.E.M. Color
1998 - 2002KTM400 SXMust have K2 or K3 ignition installed.
2005 - 2011SuzukiRM-Z450Requires aftermarket stator assembly O.E.M. Color
2003 - 2006KTM450 SX-FMust have K2 or K3 ignition installed.
1974 - 2011YamahaYZ250Requires aftermarket stator assembly O.E.M. Color
2014 - 2017SuzukiDR-Z125LRequires aftermarket stator assembly O.E.M. Color
2003 - 2013SuzukiDR-Z125LRequires stator rewind/Requires stator modification.
1975 - 2007SuzukiRM125Requires aftermarket stator assembly O.E.M. Color
2000 - 2009YamahaTTR125LRequires Stator rewind
1991 - 1997YamahaWR250O.E.M. Color
1974 - 2011YamahaYZ125Requires aftermarket stator assembly O.E.M. Color

Shipping Information

  • Item Requires Shipping
  • 5.0 lbs.
  • W6.0000” x H10.0000” x L4.0000”
  • Free Ground Shipping (1 - 5 Days)
